Sentry-H is a Software Defined Radio designed for tactical base and mobile deployment. It can also be easily upgraded for expanded capability via the convenience of software upgrades.

The Sentry-H supports high speed data and state of the art digital voice capabilities in combination with AES 256 Encryption, if required. Frequency Hopping is also available to provide a level of ECCM Protection.
Sentry-H delivers a rugged and affordable Radio solution for military organizations that demand uncompromised, secure long range voice and data communications. It has been specifically designed to deliver the smallest and lightest form factor for no-fuss integration into base and mobile configurations. Sentry-H has been optimized for ease-of-use and features an ergonomic smart handset with a colour, highresolution multi-language interface.

Main features:

  • Future-proof SDR design
  • Rugged smart handset with colour display and integrated GPS
  • Multi-language user interface
  • Optimized for mobile and base
  • 150 W PEP
  • Second Generation Digital Voice
  • MIL-STD-188-110A/B (STANAG 4539) data waveforms (up to 19k2 bps)
  • AES-256 digital COMSEC
  • Frequency Hopping
  • 3G ALE (STANAG 4538)
  • Waterproof MIL-STD-810G construction
  • IP/USB Connectivity
  • H-250 Accessories support

Download the brochure

Technical details SENTRY-H

Frequency range
1,6 - 30 MHz (Transmit) | 250 kHz - 30 MHz (Receive)
up to 1000, 500 programmable contacts
up to 20 (simultaneous scanning)
Output power
150 W
2,82 kg | (RFU) 280 g (handset, no cable)
Input voltage
10 V up to 35 V DC
RFU external antenna (SMB socket), Handset ? embedded receiver/antenna (GPS, GLONASS, Beidou)
Frequency hopping
6/12/25 hop/s (sync. GPS)
Environmental and mechanical
MIL-STD-810G Shock, Drop, Vibration, Humidity, Blowing Dust, Salt Fog, Fungus, Altitude, Immersion IP67
  • ATU Control
  • General Purpose Interface
  • Handset Interface
  • DC supply
  • H-250 6-pin MIL support audio in/out, PTT
  • GPS antenna SMB socket
  • Antenna N-type
  • Ignition Sense
  • USB Keyboard support
  • Conforms to STANAG 4538
  • Fast kin king with a high degree of link security
  • High and low throughput date waveforms
  • Secure data transfer (option)
  • Supports All calls types, including SMS (up to 250 characters)
  • Backward compatible with 2G networks
